Beam aperture discs, or large area pinholes, are an inexpensive, simple solution for limiting the angular aperture at the input of a Monochromator or detector, or attenuating light. These beam aperture discs are made of aluminum and can be placed into any optic holder compatible with 1.0 inch diameter optics.
| Compare | Model | Drawings, CAD & Specs | Availability | Price | |||
|---|---|---|---|---|---|---|---|
|
70275 Beam Aperture Disk, 1.0 inch Diameter, 0.4 inch Aperture | $75.00 |
|
||||
|
|
70276 Beam Aperture Disk, 1.0 inch Diameter, 0.2 inch Aperture | $60.00 |
|
||||
|
|
70277 Beam Aperture Disk, 1.0 inch Diameter, 0.1 inch Aperture | $60.00 |
|
||||
|
|
70291 Beam Aperture Disk, 1.0 inch Diameter, 0.04 inch Aperture | $47.00 |
|
All beam aperture disks are 1.0 inch outside diameter for compatibility with 1.0 in optic mounts. They are offered with a fixed 0.04, 0.1, 0.2 or 0.4 inch aperture. These are effectively large area pinholes for incoherent light sources such as Xenon lamps used in Oriel® Research Arc Lamp or Q Series Lamp Housings.
